Type
swiss air PAPR system, battery powered
Protection level
TH3 (EN12941)
BLOWER UNIT
Flow rates
- level 1: min. 100 l/min
- level 2: min. 115 l/min
- level 3: min. 130 l/min
- All levels with automatic air flow control (levels are set directly on the fan and can be continuously adjusted via the control panel at the front).
Material
PA66 GF30
Fan
high quality ball beared motor
Fuse
electronic
Noise
max. 70db (A)
Alarm
optical (with swiss air Control Panel) and audible alarm for low / very low battery, clogged filter, no filter, and low flow
Low battery: alarm period: 3.0s (1.5s on, 1.5s off)Filter: alarm period 0.5s (0.25s on, 0.25s off)
Dimensions (L x W x H)
250 x 170 x 50 mm
Weight
Blower unit 550 g / Overall system 1,200 g
Color
black
HALF-MASK
Material
ripstop textile (98% polyester and 2% polyurethanesInlay: Polyurethane foam
Valves
2 exhalation valves with silicone membrane
Color
black
HEADBAND / NECK BAND
Material
Neoprene / elastic
Color
black
FILTER UNIT
Type
TH3P R SL filter for TH3P System (EU) with pre-filter
HOSE
Material
POM and siliconeLength180 mm (elastic, up to 355 mm excl. Y-hose)Internal diameter21 mm
Color
black
BATTERY PACK
TypeLi-Ione, rechargeable, 3,6 V / 6,5 Ah / 23.4Wh
Operating time
6 up to 12 hours(Operating time depending on air flow, at room temperature with a new filter.)
Charging time
appr. 6h
Sleep mode
after 3 hours, activation by pressing once, start at second press
CERTIFICATES
Standards
EN 12941
Europe: TH3
Australia: P3
AS/NZS 1716
EAC TP TC 019/2011
Notified body
CE 1024
Scope of delivery
Blower unit with hose, half-mask, TH3P R SL filter, battery, harness, charger, charging cable user instructions
Warranty
from date of purchase: 2 years for manufacturing and material defects, 6 months for battery
Note
The optrel SWISS AIR respiratory system may NOT be used in environments where there is an immediate danger to health or life (IDLH), in atmospheres containing less than 17% (Europe) oxygen or where the concentration of toxins is so high that a protection class in excess of TH3 (EU) is required. It is NOT evaluated as an ignition source in flammable or explosive atmospheres.
