Shade levels
- ShadeTronic inactive: shade level 3.0active, manual: shade levels 8-13
- ShadeTronic 4-13 with individual calibration option ± 2.
Energy supply
solar cells, Li polymer battery pack, chargeable via Micro-USB
Battery life range
300 to 500 charging cycles
Sensoric
Five sensors
Sensitivity
continuously, new with “Super High” sensitivity
Switching time
- light to dark:0.090 ms at 20°C0.070 ms at 55°C
- dark to light:0.1 s to 2.0 s (with FadeTronic)
Field of vision
2.3 to 6.3 times bigger than a 100 x 50 mm standard ADF
Classification EN379
1/1/1/1
Shape stability
- Mask: up to 220°C
- Front cover lens: up to 137°C
Eye protection
UV/IR protection: maximum protection at all shade levels
Operating temperature
-10°C to + 55°C / 14°F to 131°F
Storage temperature
-20°C to + 70°C / -4°F to 158°F
Weight
575 g / 20.3 oz (PAPR 745g)StandardsCE, ANSI, EAC, AS/NZS, compliant with CSA Z94.3, additionally with PAPR version EN 12941 (TH3) and suppliedair version EN 14594 (3B). Compliant with pr ISO 16321 standard „WIG+“ („low amp Tig“)
Scope of delivery
Welding helmet, optrel IsoFit® headgear, manual, bag, Micro USB cable, front cover lens, warranty card
Warranty
from date of purchase: 2 years for manufacturing and material defects, 6 months for battery
Warranty extension
1 year additional (battery excluded) for online product registration within the first 6 months (from date of purchase) on optrel.com/registe
