EAGLE 545 FGS | All Position, High Deposition, Machinable, Gas Shielded Flux Cored Wire For Build-up

EAGLE 545 FGS

Name: EAGLE 545 FGS
Brand: Eagle Alloys Welding
Price: 1379.04 CAD
Availability: InStock

$1,379.04 CAD

Size 0.045"

0.045" 1/16"

Weight

44 LB (20 KG) Spool

Free Shipping to Canada

Description Description

All Position, High Deposition, Machinable, Gas Shielded Flux Cored Wire For Build-up

APPLICATIONS APPLICATIONS

High quality alloy for build-up and as an underlay on low, medium, and high carbon steels. This wire is excellent for metal to metal wear

PROCEDURE PROCEDURE

DC Reverse (+] Polarity. Use the grinding method or remove fatigued metal using the EAGLE 188. Use the lowest effective amperage while maintaining a 1/2 - 5/8 inch stick out length making either stringer beads or weave beads.

GENERAL CHARACTERISTICS GENERAL CHARACTERISTICS

The EAGLE 545 FGS is an all positing build-up wire with a martensite structure and has stable hardness because it contains carbide forming elements.

TECHNICAL DATA TECHNICAL DATA

Current: DC Reverse [+] Polarity
Hardness: (RC) Approx. 40 - 45

WELDING PARAMETERS WELDING PARAMETERS

Sizes: Inches .045 1/16
mm 1.20 1.60
Volts: 20 - 26 22 - 27
Amperage: 150 - 250 240 - 340
Gas Flow: 35 - 45 CFH
Shielding Gas: 75/25 Ar/CO₂ or 100% CO₂
