EAGLE 674

Name: EAGLE 674
Brand: Eagle Alloys Welding
SKU: 674_11.00_2
Price: 336.1 CAD
Availability: InStock

$336.10 CAD

Diameter 7/16"

7/16" 1/4" 5/16"

Size

Description Description

Hardfacing For Extreme Abrasion At High Temperature

APPLICATIONS APPLICATIONS

High quality alloy for parts subject to extremely high abrasion by coal, ore, sand, cement, and gravel. Deposits are highly resistant to abrasion and erosion at elevated temperatures up to 1000°F.

PROCEDURE PROCEDURE

Use AC or DC Reverse [+] Polarity. Use the grinding method or remove fatigued metal using the EAGLE 188.
Use lowest effective amperage while maintaining a medium arc length making either stringer beads or weave beads.

GENERAL CHARACTERISTICS GENERAL CHARACTERISTICS

The EAGLE 674 Chrome Plus is a high quality hard surfacing electrode with excellent weldability in all positions.
Thin wall tubular electrode for very low amperage.

TECHNICAL DATA TECHNICAL DATA

Tip Colour: Red

Hardness: (RC) Approx. 58 - 62

WELDING PARAMETERS WELDING PARAMETERS

Current: AC or DC Reverse [+] Polarity
Sizes: Inches 1/4, 5/16, 7/16
mm 6.00, 8.00, 11.00
Amperage: 80 - 125, 130 - 200, 200 - 370
